Pneumatic Pipe Alignment Clamp Pipe Fitting Clamp Internal Line Up Clamp






Introduction

HGND-C series copper lining pneumatic internal line up clamp is mainly used for pipeline construction of automatic welding and semi-automatic welding. It has the function of conventional pneumatic internal line-up clamp features. Meanwhile, it has copper lining features. That is, during the welding process, the copper lining closely fitted to the inner wall of welding road, and achieve the purpose of unilateral welding and double-sided forming. It is an ideal and decicated pipeline construction that can conduct welding automatically and deal with the problem of difficult root welding during the semi-automatic welding process. Suhigo copper lining pneumatic internal clamp has been used in pipeline construction in domestic market and overseas market.

Model Pipe Size Piston No.s Piston Power L W H Weight Cube
(mm) (KN) (mm) (mm) (mm) (kg) (m3)
HGDNQ6’’ 168 6X2 134 1473 150 150 36 .04
HGDNQ8’’ 219 6X2 209 1593 189 189 53 .06
HGDNQ10’’ 273 6X2 382 1665 240 240 60 .09
HGDNQ12-14’’ 305-357 6X2 405 1751 280 280 100 .14



Feature

1.The Internal Pneumatic Line-Up Clamp is for pipe laying barge and onshore project use.
2.The pneumatic Internal line-up clamp is specially for aligning pipes before pipeline welding process,large range from 6" to 80", FESTO Valve, Ingersoll or German COOPER drive motor and optimal design proved its best on site performance on offshore pipe laying barge and onshore project.
3. Copper back up shoes system would be equipped in internal line-up clamp for automatic welding system.
4. Purge system for argon welding can equipped in the internal line up clamp for CRA pipeline project.
5.Internal line up clamp which is pneumatic controlled for clamp shoe expanding / retract and electrical valve for motion control, is popular in offshore pipe laying.
6.There are also self-propelled and self-braking settings for Internal Pipe Alignment Clamp DKQ406 and above models,traveling speed:0-1M/S.



Internal Pipe Alignment Clamps Pipe Beveler Machine For Gas Pipeline Welding 0Internal Pipe Alignment Clamps Pipe Beveler Machine For Gas Pipeline Welding 1



Model Pipe Size Piston No.s Piston Power Motor Power Motor Nos. L W H Weight Cube
(mm) (KN) (hp) (mm) (mm) (mm) (kg) (m3)
HGDNQ16-18’’ 406-457 8x2 959 1 1 2132 360 360 188 .29
HGDNQ20-22’’ 508-559 10x2 1057 1.5 1 2434 480 480 296 .59
HGDNQ22-24’’ 559-610 12x2 1268 1.5 1 2500 530 530 390 .72
HGDNQ24-26’’ 610-660 12x2 1268 1.5 1 2672 580 580 418 .90
HGDNQ28-30’’ 711-762 12x2 1748 1.5 1 2700 670 670 512 1.2
HGDNQ30-32’’ 762-813 14x2 2937 3 1 2938 690 690 733 1.4
HGDNQ34-36’’ 864-914 16x2 2937 3 1 3020 790 790 779 1.8
HGDNQ36-38’’ 914-965 18x2 2937 3 1 3188 860 860 865 2.4
