70T Pipe Layer For Oil Gas Pipeline Construction Oil Gas Pipe Laying Machine

70T Pipe Layer For Oil Gas Pipeline Construction Oil Gas Pipe Laying Machine

70T Pipe Layer

Pipeline Construction Pipe Layer

Oil Gas Pipe Layer

Place of Origin:


Brand Name:



ISO9001 OHSAS18001 CE

Model Number:


Contact Us

Request A Quote
Product Details
Planetary Gears, Forced Lubrication Power Shift
Applicable Industries:
Oil&Gas Pipeline Construction
Pplicable Temperature:
Mobile Type:
Tracked Construction Machinery
Product Name:
HGY70 Pipe Layer
Product Model:
Cummins NT855-C360
Payment & Shipping Terms
Minimum Order Quantity
1 pcs
Packaging Details
Seaworthy- Integral wax spraying anti-corrosion
Payment Terms
T/T, L/C
Product Description

Product Description:

Our HGY70 Pipe Layer is a Mobile type Tracked Construction Machinery. It measures 5630×3400×3540mm, making it compact and easy to maneuver in tight spaces. The machine is built to withstand extreme temperatures, with an applicable temperature range of -45℃~+60℃. Whether you're working in the freezing cold or scorching heat, our machine will get the job done.

Our Pipeline Construction Machinery is designed to make laying pipes easier and more efficient. The HGY70 Pipe Layer is equipped with a range of features that make it the ideal choice for pipeline construction projects. The machine's Planetary Gears provide smooth and reliable power transfer, while the Forced Lubrication Power Shift ensures that the machine is always operating at peak efficiency.

Our Pipe Laying Machines are also designed with safety in mind. The HGY70 Pipe Layer is equipped with a range of safety features, including a ROPS (Roll Over Protection System) and FOPS (Falling Object Protection System). These features help to protect operators and ensure that the machine is always operating safely and efficiently.

At our company, we pride ourselves on providing high-quality Pipeline Construction Machinery that meets the needs of our customers. Our HGY70 Pipe Layer is no exception. With its durable construction, efficient design, and reliable performance, our machine is the perfect choice for pipeline construction projects of all sizes. Contact us today to learn more about our Pipe Laying Machines and how they can help you get the job done.


70T Pipe Layer For Oil Gas Pipeline Construction Oil Gas Pipe Laying Machine 0


1.HGY series pipelayers provided by our company is a specialized pipeline construction equipment, mainly used in lifting, transportation and laying of pipeline .
2.The equipment adopts the special chassis of the pipelayer developed based on the bulldozer chassis,
3.Walking system adopts mechanical transmission and lever operation.
4.Working device adopts hydraulic transmission, operated handle , the transmission efficiency is high, and the work is stable. It is an international popular pipelayer configuration.



Device model HGY25 HGY45 HGY70 HGY90 HGY105


Lifting Capacity t

25 45 70 90 105
quality (approx.) t 22 35 49.5 55 62
Host transport size mm 4135×3050×3015 4750×3350×3270 5906×3334×3100 5906×3354×3100 6045×4120×3980
host transport quality t 18.5 26 37.5 38.9 42.5

Minimum ground clearance


480 490 550 550 575
gauge mm 2050 2250 2380 2490 2550
Track shoe width mm 560 660 760 860 860
power/speed kW /rpm 131/2200 183/ 2000 257/2000 257/2000 310/2000
Arm lengt(customizable)mm 6000 7500 8600 9600 9600



The HGY70 Pipe Layer is perfect for use in extreme weather conditions as it can operate in temperatures ranging from -45℃ to +60℃. The machinery is designed for oil and gas pipeline construction and is particularly useful in the laying of large diameter pipelines.

This pipeline construction machinery is versatile and can be used for both onshore and offshore pipeline construction projects. Its mobility and flexibility make it a valuable asset for pipeline construction companies. The product has a minimum order quantity of 1 piece and the price is negotiable.

The HGY70 Pipe Layer is painted in a bright yellow color for high visibility and can be easily tracked during operation. The product is packaged using seaworthy integral wax spraying anti-corrosion to ensure that it is protected during transportation.

The payment terms for this pipeline laying machine include T/T and L/C. The product is suitable for use in a variety of pipeline construction scenarios such as laying pipelines in remote areas, mountainous terrain, and other challenging locations.

This pipe laying machine is a valuable investment for any pipeline construction company. Its mobility, versatility, and durability make it a must-have for any pipeline construction project. Contact us today to order your Suhigo HGY70 Pipe Layer.


70T Pipe Layer For Oil Gas Pipeline Construction Oil Gas Pipe Laying Machine 1

Why choose suhigo?

1) Suhigo is professional manufacturer, obtained ISO9001, ISO14001, GB/T28001 HSE Certificates, and CE certificate.

2) Suhigo has rich project experience with CPP, CNPC and SINOPEC branch oil construction companies.

3) Pipelayer cabin can be provided with ROPS & FOPS certificates, for option.

4) Suhigo product has exported to Russia, Middle Asia, Middle East, Africa etc.

5) Suhigo factory covers 30,000m2 and has 100+ workers including office, workshop and field service personnel.
