90T Side Boom Pipe Layer Pipeline Machines Crawler Pipelayer

90T Side Boom Pipe Layer Pipeline Machines Crawler Pipelayer

90T Side Boom Pipe Layer

Pipe Layer Pipeline Machines

Pipeline Machines Crawler Pipelayer

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Product Name:
HGY90 Pipe Layer
ISO9001 OHSAS18001 CE
Applicable Industries:
Farms, Retail, Construction Works , Energy & Mining
Yellow And Red
Operation Mode:
Hydraulic Control
Hydraulic Drive
Planetary Gears, Forced Lubrication Power Shift
Payment & Shipping Terms
Minimum Order Quantity
1 pcs
Packaging Details
Seaworthy- Integral wax spraying anti-corrosion
Delivery Time
Payment Terms
T/T, L/C
Product Description

90 Ton Large Side Boom Pipe Layer HGY90(90Tons)crawler pipelayer Made In China Best selling equipment


1.HGY series pipelayers provided by our company is a specialized pipeline construction equipment, mainly used in lifting, transportation and laying of pipeline .
2.The equipment adopts the special chassis of the pipelayer developed based on the bulldozer chassis,
3.Walking system adopts mechanical transmission and lever operation.
4.Working device adopts hydraulic transmission, operated handle , the transmission efficiency is high, and the work is stable. It is an international popular pipelayer configuration.



HGY90 hydraulic crawler pipelayer is a mature product developed according to the market demand and combined with the experience of the original pipelayer. This series of products adopts the domestic well-known Shantui crawler-type pipelayer special chassis, the transmission system is a trinity hydraulic transmission mode of engine, torque converter and gearbox, and the power equipment is Cummins series engines of domestic well-known brands.


型号 Model


Maximum lifting capacity

90t/ 200000lb

Rated lifting weight

77t/ 170000lb

Operating Weight

55t / 121000lb

Overall size(mm)


Host transportation quality


Average grounding ratio


Minimum ground clearance


Maximum climbing ability


Applicable temperature




Cummins NT855-C360

Rated power


Rated speed









  • Adopt large gauge chassis to improve the stability of the whole pipelayer
  • Walking System adopts mechanical transmission and level operation
  • Working device adopts hydraulic transmission, joystick operation
  • Complete safety devices to ensure lifting safety
  • ROPS/FOPS structure with certificate for option


The lifting system adopts open hydraulic transmission with gear pump oil supply with strong anti pollution ability and self-priming ability, with stable transmission, stepless speed change, good micro motion performance and strong adaptability.
The lifting hook and boom luffing are controlled by hydraulic winch, and the counterweight retraction and release are controlled by hydraulic oil cylinder, which meets the requirements for efficiency and accuracy during pipe crane operation.
The boom is welded with HG60 high-strength steel, with light weight and high strength.


90T Side Boom Pipe Layer Pipeline Machines Crawler Pipelayer 0

90T Side Boom Pipe Layer Pipeline Machines Crawler Pipelayer 1




About Suhigo

  1. As China Specialist in Pipeline Construction Equipment Manufacturing., Suhigo can offer premium pipelayers or sideboom to help achieve the target of lifting pipe, moving to position and placing pipe. Suhigo Pipelayer Family have full line lifting weight pipelayers equivalent to International Pipelayer brand, size ranging from 25tons to 90tons. With decades experience, all pipelayers are designed to full safety, reliable performance and easy operation, can work flexible with different size pipeline construction projects throughout the globle. Up to now, Suhigo have worked with Oil Construction companies of CNPC, Sinopec and CPP.
  2. Looking to acquire brand new pipelayers or sidebooms for your tender ? Check out the latest introduction of Pipelayers from Suhigo. Except for brand new pipelayers, we may have some used pipelayers in stock with good quality, welcome to contact us for more information.



90t pipelayer data list (single unit)


No. Name  Quantity(piece)
1 HGY90 Pipelayer Instruction Manual 1
2 HGY90 Pipelayer Parts Catalog 1
3 Pipelayer certificate 1
4 SD32 Bulldozer Parts Catalog 1
5 NT Series Diesel Engine Operation and Maintenance Manual 1
6 NT(A)855-C S10 Parts Catalog 1
7 Chongqing Cummins diesel engine product certificate 1
8 Chongqing Cummins Global Service Network 1
9 Cummins Diesel Engine Special Oil Instruction Manual 1
10 Pipelayer chassis certificate
